QSC PL340

pl340
86,000.00 THB ต่อหน่วย Manufacturer: QSCQSC

รายละเอียดย่อ :
PowerLight 3 Series 800 Watt Professional Power Amplifier
รายละเอียดทั้งหมด :



QSC PL340  PowerLight 3 Series 800 Watt Professional Power Amplifier

PowerLight 3 Series

Professional Power Amplifiers




PL325 | PL340 | PL380


The PowerLight™ 3 Series is designed for the most demanding live audio users, whether in touring rigs or fixed installations. The most requested features of the PowerLight 2 series have been upgraded to deliver "the ultimate analog amplifier", while the QSC Dataport ensures full compatibility with advanced digital processing and QSControl.net™. Three models range in power from 1250 watts to 4000 watts per channel at two ohms, all in two-rack space chassis that are only 15.6" (40 cm) deep and 22 lbs (10 kg).




Q-Sys Compatible

Advanced monitoring and control when used with a Q-Sys or BASIS system. Learn more

In addition to higher power, the PowerLight 3 Series offers higher input voltage, selectable sensitivity, and easily adjusted rear panel switches with color coded LED indicators. For those users who simply want a high performance amplifier to go with their existing processor or console, the PowerLight 3 Series is an ideal choice, offering high power, excellent value, and zero signal latency. When complete integration of amplifier control, monitoring and DSP is desired, the PowerLight 3 Series is fully compatible with the QSControl.net BASIS™ networked audio platform, with its comprehensive drag and drop DSP functionality. Simpler DSP requirements can be met with the DSP-4 processing module.



PowerLight 3 Power Amplifiers
Watts at Clipping
  Watts per channel
Model 8 ohms 4 ohms 2 ohms
PL325 500 850 1250
PL340 800 1250 2000
PL380 1500 2500 4000*
EIA 1 kHz 1% THD
* Burst mode testing required due to AC service current limitations

Comprehensive full range power ratings with explanations can be found in the following paper: Full Range Power Ratings for PL3 Series (PDF 308K)

The flagship of the PowerLight 3 Series is the new 8000 watt PL380. This highly refined, all-switchmode amplifier incorporates nearly 40 years of QSC engineering experience, resetting expectations for Class D audio quality. The PL380 combines a pair of 4000 watt Class D amplifier channels with the well proven PowerLight supply, to deliver more than twice as much audio power as previous 2 rack unit PowerLight amplifiers. Reactive "back EMF" from the speaker is recycled to the power supply, and unmatched "plug-to-plug" efficiency of 85% keeps AC power needs to a minimum, while delivering more energy to the speaker.

Years of patient development have resulted in outstanding 20 Hz - 20 kHz audio performance, plus complete protection from normal hazards of the trade. Even simple features such as dependably silent, surge-free on/off switching indicate the special care taken to keep things safely under control. The most pronounced "sonic signature" of the PL380 is one of immense headroom, sailing through even the most difficult loads with no signs of stress or change of tonality.

For lower power applications, the PL325 and PL340 offer the same feature set, matched to upgraded versions of QSC's most advanced linear amplifier platform. Recent advances in power supply capacitors further improve power and low impedance performance, while continuing to offer the best available audio performance. As a result, designers have the choice of running a single type of amplifier throughout their rig, or matching amplifier performance to specific transducer types.

In keeping with normal QSC design standards, back-to-front airflow provides up to twice as much long-term average power as most competitors, without dumping hot air into the rack. All PowerLight 3 models are built in the same chassis size, with common back panel layouts to facilitate easy racking and hookup.


FEATURES

  • PowerLight switchmode power supply for highest efficiency and improved audio performance
  • Flow-thru air path and solid aluminum heat sinks for maximum cooling
  • DataPort supports remote computer control and/or external DSP-4 modules
  • Detented gain controls with 1 dB steps for precise calibration
  • Removable knobs with lock-out security plate to prevent unauthorized tampering
  • User defeatable clip limiters and selectable low-frequency filter per channel (3 Hz, 30 Hz, or 50 Hz)
  • Three selectable input gains (26 dB, 32 dB, or 1.2 V)
  • Front and rear panel LEDs indicate status of switch settings at a glance
  • Parallel Dataport, XLR/M and XLR/F connectors for simple loop-through connectivity
  • Neutrik Speakon® and "Touch Proof" binding post outputs
  • Neutrik Powercon® power cable remains secure on the road
  • 3 year warranty, plus optional 3 year extended service contract

PL340 and PL325

  • Linear Class H output circuit doubles standard Class B efficiency to reduce AC current consumption and cooling requirements

PL380

  • Class D output circuit re-doubles the output power with even lower losses and minimal increase in average AC power, dramatically reducing power distribution demands compared to older high power amplifiers

PowerLight 3
SPECIFICATIONS PL325 PL340 PL380
  STEREO MODE, Both Channels Driven
8 ohms EIA 1 kHz 1% THD 500 W 800 W 1500 W
4 ohms EIA 1 kHz 1% THD 850 W 1250 W 2500 W
2 ohms EIA 1 kHz 1% THD 1250 W 2000 W 4000 W*
  BRIDGE MONO MODE
8 ohms EIA 1 kHz 1% THD 1700 W 2600 W 5000 W
4 ohms EIA 1 kHz 1% THD 2500 W 4000 W 8000 W*

Typical Distortion
(20 Hz -3 kHz, 3dB below clip, or 20 Hz -
5 kHz, 10dB below clip, or 20 Hz - 20 kHz, 20dB below clip)
8 ohms
4 ohms
2 ohms




0.002-0.01%
0.005-0.01%
0.02%




0.002-0.01%
0.005-0.01%
0.02%




0.01-0.03%
0.03-0.06%
0.1%
Maximum Distortion
(20 Hz - 20 kHz, 1 dB below rated power)
4 to 8 ohms



0.05%



0.05%



0.2%
Frequency Response (8 ohms) 20 Hz - 20 kHz, +/-0.2 dB 20 Hz - 20 kHz, +/-0.2 dB 20 Hz - 20 kHz, +/-0.2 dB
Noise (20 Hz - 20 kHz, 32 dB Gain) -106 dB -105 dB -104 dB
Dynamic Headroom (4 ohms) 2 dB 2 dB 2 dB
Damping Factor (8 ohms) 500 500 200
Output Circuitry Class H (2-tier) Class H (2-tier) Class D
Input Sensitivity
  26 dB Setting
  32 dB Setting

3.28V
1.60V

3.92V
1.96V

5.27V
2.67V
Input Gain (1.2V setting) 34.5 dB 36.4 dB 39.1 dB
Maximum Input Level
  1.2V setting
  32 dB setting
  26 db setting

11V (+23 dB)
14.6V (+25.5 dB)
25V (+30 dB)

11V (+23 dB)
14.6V (+25.5 dB)
25V (+30 dB)

10V (+22 dB)
22V (+29 dB)
25V (+30 dB)
AC Power Requirements **
  120V 50/60 Hz
  230V 50 Hz

8.5A
7.5A

12A
7A

18A
11A
Cordset
  120V 50/60 Hz
  230V 50 Hz

NEMA-15
CEE 7/7 16A

NEMA-15
CEE 7/7 16A

NEMA L5-30P
CEE 7/7 16A
Chassis Power Connector
  All Voltages

20A PowerCon

20A PowerCon

32A PowerCon
  ALL MODELS
Input Impedance > 10k ohms balanced, or unbalanced
Cooling Variable-speed fan, rear-to-front air flow
Connectors (each channel) Input: XLR Male, XLR Female and 3-pin detachable terminal blocks (1 each per channel)
Output: Neutrik Speakon® (ch 1 wired to both channels) and 5-way binding posts
DataPort: HD-15, input signal in parallel with XLR input connectors
Front Controls AC Power Switch
Gain Controls, 21 detents, 1 dB steps (each channel)
Front indicators (LED color) Power (Blue)
Bridged (Yellow)
Parallel (Orange)
Clip/Prot (Red x 2)
Level -10 (Orange x 2)
Level -20 (Green x 2)
Signal -35 (Green x 2)
Rear Controls (with LED indicators) Input Mode: Bridge (Yellow), Stereo (Green), or Parallel (Orange)
Gain / Sensitivity: 26dB (Orange), 32dB (Green), or 1.2V (Yellow)
High Pass (each channel): 3 Hz (Off), 30 Hz (Yellow), or 50 Hz (Orange)
Clip Limiter (each channel): Off, On (Yellow)
Amplifier and Load Protection Short circuit, open circuit, thermal, RF protection. On/off muting, DC fault shutdown, active inrush limiting
Dimensions Height: 3.5" (8.9 cm) 2RU
Width: 19" (48.3 cm)
Depth: 15.63" (39.7 cm) from front mounting rails
Weight Net: 22 lbs (10 kg)
Shipping: 31.5 lbs (14.3 kg)
Net: 24 lbs (11 kg)
Shipping: 33.5 lbs (15.2 kg)
Agency Approvals UL, CE, RoHS/WEEE compliant, FCC Class B (conducted and radiated emissions)

U.S. Patent no. 5767744 and patents pending
*Burst mode testing required due to AC service current limitations
** Representative of current draw with typical music program material with occasional clipping
